Experimental results of DPC and ACDPC on NIH 3T3 cells

Caption

Figure 3: Experimental results of DPC and ACDPC on NIH 3T3 cells. (a) Experimental result of DPC and ACDPC experiments on NIH 3T3 cell samples under fine focusing conditions. (b) Magnified images of two ROIs (ROI 1, ROI 2) in (a). (c) Zernike coefficient of retrieved aberration in (b). (d) Experimental result of DPC and ACDPC experiments on NIH 3T3 cell samples under coarse focusing conditions. (e) Magnified image of the ROI (ROI 1) in (a) and further magnification of its ROI (ROI 2). (f) Zernike coefficient of retrieved aberration in (e).

Credit

Yao Fan, Chenyue Zheng, Jiasong Sun, Chao Zuo, Qian Chen
