Experimental results of USAF resolution targets.

Caption

Figure 2: Experimental results of USAF resolution targets. (a) ACDPC experimental system based on commercial inverted microscope with annular illumination. (b) The actual acquired intensity image and the zoom-in image of region of interest (ROI 1). (c) Full-field-of-view reconstructed phase and zoom-in images (ROI 1) of DPC and ACDPC at −10μm defocus, and quantitative phase profile. (d) Reconstructed phase and zoom-in images (ROI 2) of DPC and ACDPC at +10μm defocus. (e) Reconstructed phase of DPC and ACDPC at +20 μm defocus and the retrieved aberration coefficient.

Credit

Yao Fan, Chenyue Zheng, Jiasong Sun, Chao Zuo, Qian Chen
