OpSIS Graphic (IMAGE)

University of Washington

OpSIS Graphic

Caption

This is a graphic of a recently built silicon photonic chip measuring 1 cm by 2 cm. At the bottom is a photograph of the chip. Above it, in green, is the original chip design. The rectangle on the upper left shows how layers of silicon (blue), metal (gray) and electrical insulator (orange) combine to create channels, or waveguides, for light to pass through.

Credit

A. Spott, University of Washington

Usage Restrictions

For news media only.

License

Licensed content
