Depiction of the digital data acquisition system (IMAGE)
Caption
The digital data acquisition system operates at a sampling rate of 250 MHz with a 14-bit resolution by Pixie-16 digitizer. Using waveform digitization technology, it converts analog signals into digital signals through high-speed sampling and precise quantization, enabling the accurate capture of energy, timing, and position information from decay particles. The trigger module is used to implement the complex logical triggers required in the experiment.
Credit
Xin-Xing Xu
Usage Restrictions
Credit must be given to the creator. Only noncommercial uses of the work are permitted.
License
CC BY-NC
