“Focused” magnet system (IMAGE)
Caption
“Focused” magnet system consisting of two stacked rings, each with 16 FeNdB magnet cuboids (side length 20 mm). The inner diameter is 160 mm, and the magnetic field of 20 mT exhibits a homogeneity of approximately 5 per mille over a spherical volume with a diameter of 50 mm.
Credit
© Peter Blümler
Usage Restrictions
Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.
License
CC BY-NC-ND
